manual attack

protection

Standards and Classifications.

Manual attack protection is measured against sustained attack by professional invaders using a variety of tools such as drills. Manual Attack resistance is rated by the European Standard (EN) and Loss Prevention Certification Board (LPCB) with the higher the numerical rating meaning a higher level of protection on offer.

Manual Attack Resistance in accordance with EN 1627 are classified in RC1-6, offering:

  • Resistance to a static charge (EN 1628)

  • Resistance to a dynamic charge (EN 1629)

  • Resistance to manual break-in (EN 1630)

Manual Attack Resistance in accordance with the EN 356 standard is classified as:

  • Resistant to vandalism (P1A – P5A)

  • Resistant to break-in (P6B – P8B)

Manual Attack Classifications (Doors + Enclosures).

Manual attack, bullet, blast, and fire resistance products can be tested to different certification levels. Different levels of certification offer different levels of protection, find out more about the widely recognised standards within the industry here.

Hammers

Manual Attack (EN 1630) Classification RC1 (No Manual Attempted Attack)

Glazing Resistance: n/a

Tool Types: A1 (hammers, spanners, tweezers, hooking wire, sledgehammer allen keys, etc)

Resistance Time: n/a

Total Test Time: n/a

Saw

Manual Attack (EN 1627) Classification RC2



Glazing Resistance: P4A

Tool Types: A2 (A1 + various hacksaws and blades, long screwdrivers, wedges)

Resistance Time: 3 mins

Total Test Time: 15 mins

Crowbar

Manual Attack (EN 1627) Classification RC3



Glazing Resistance: P5A

Tool Types: A3 (A2 + hand drill, drill bits, punches, hammer, wedging bar)

Resistance Time: 5

Total Test Time: 20 mins

Buzzsaw

Manual Attack (EN 1627) Classification RC4

Glazing Resistance: P6B

Tool Types: A4 (A3 + club hammer, chisel, cutters, hand axe, bolt cropper, power drill)

Resistance Time: 10 mins

Total Test Time: 30 mins

Buzzsaw

Manual Attack (EN 1627) Classification RC5



Glazing Resistance: P7B

Tool Types: A5 (A4+ Mini angle grinder, power drill, reciprocating saw, SDS Drill, hole cutter)

Resistance Time: 15

Total Test Time: 40

Nail gun

Manual Attack (EN 1627) Classification RC6

Glazing Resistance: P8B

Tool Types: A6 (A5 + angle grinder, percussion drill, axe hammer, etc)

Resistance Time: 20 mins

Total Test Time: 50 mins

Manual Attack Classifications (Windows + Glazing).

Manual Attack (EN 356) Classification P1A

Drop height of a steel ball (m): 1.5

Number of impacts (triangle of 130mm): 3

Manual Attack (EN 356) Classification P2A

Drop height of a steel ball (m):

No. of strikes (triangle of 130mm): 3

Manual Attack (EN 356) Classification P3A

Drop height of a steel ball (m): 6

Number of impacts (triangle of 130mm): 3

Manual Attack (EN 356) Classification P4A

Drop height of a steel ball (m):

No. of strikes (triangle of 130mm): 3

Manual Attack (EN 356) Classification P5A

Drop height of a steel ball (m): 9

Number of impacts (triangle of 130mm): 9 (3 impacts x 3 points)

Manual Attack (EN 356) Classification P6B

Total number of strikes: 30 – 50

Manual Attack (EN 356) Classification P7B

Total number of strikes: 51 – 70

Manual Attack (EN 356) Classification P8B

Total number of strikes: Over 70

Resistance in action.

LPCB Accredited Door Test

We went through the rigorous testing programme for our Stalwart Steel Door and are pleased to report that it achieved a LPCB LPS1175 SR4 issue 8 rating for manual attack. This means our product can now be found here listed on The Red Book alongside other security products which offer exceptional levels of security.

Re-enhanced Petrol Forecourt Door

Not only do we sell security doors, but we can also re-enhance any commercial doors to a higher security level, withstanding attack for a much longer period, depending on specification and project requirement.

Our team of industry experts provides a professional service and a personal response to customers’ needs, we build relationships that you can trust. Our fully accredited and trusted product portfolio is designed to meet the changing needs of our customers
